Sefa e-Duplex Air Pro 40cm x 50cm Heat Press

The SEFA e-Duplex Air Pro 40cm x 50cm Heat Press is SEFA's advanced dual-station pneumatic press for high-volume production, combining the automation of the e-Duplex Pro with membrane platen technology for decorating thicker garments and products with uneven or raised surfaces.

The press features two full-size 40 x 50 cm (16" x 20") standard lower platens along with 45 x 55 cm (18" x 22") membrane platens. When the membrane system is used, the platen inflates to conform around garment irregularities such as thick seams, zippers, buttons, pockets, linings, and other raised areas. This helps create more even pressure across the transfer area and makes it possible to decorate products that can be difficult to press on a conventional flat platen.

The e-Duplex Air Pro also features automatic opening, closing, and heating-head shuttle movement between its two workstations. While one item is being pressed, the operator can prepare the opposite station, creating an efficient continuous production workflow. A foot pedal provides hands-free cycle control, allowing both hands to remain available for garment and transfer positioning.

With three selectable operating modes—single-platen, semi-automatic, and fully automatic—the e-Duplex Air Pro can adapt to different jobs and production requirements. Pneumatic pressure up to 625 g/cm², support for materials up to 45 mm thick, and a powerful 2200 W heating system provide the versatility needed for heat transfer vinyl, screen print transfers, sublimation, ChromaLuxe®, laser transfers, DTG-related applications, and specialty workwear decoration.

SEFA's multifunction touchscreen provides independent timing and preheating settings for each workstation, along with 10 programmable recipes, adaptive temperature regulation, Eco Mode, Standby Mode, and dual production counters. For professional decorators handling high-volume apparel production as well as jackets, uniforms, workwear, and other challenging garments, the e-Duplex Air Pro offers exceptional flexibility, automation, and pressure control.

Key Features

• Standard and membrane platen capability – Handles conventional flat products as well as thicker garments with raised or uneven surfaces
• Inflatable membrane platens – Conform around seams, zippers, buttons, pockets, linings, and other garment reliefs for more even pressing pressure
• Dual 16" x 20" standard workstations – Prepare one garment or substrate while the opposite station is being pressed
• 45 x 55 cm membrane platens – Provide a larger membrane surface with a 40 x 50 cm usable pressing area
• Automatic head shuttle – Automatically moves the heating head between both workstations
• Pneumatic opening and closing – Provides consistent pressure while reducing repetitive operator effort
• 3 operating modes – Choose between single-platen, semi-automatic, or fully automatic operation
• Foot-pedal control – Allows hands-free cycle activation for easier garment positioning
• Up to 625 g/cm² pressure – Provides strong and repeatable pneumatic pressure for demanding applications
• Up to 45 mm material thickness – Accommodates thicker garments, substrates, and specialty products
• 2200 W heating system – Provides strong heating performance for transfer and DTG pretreatment applications
• Quick-change platen system – Makes it easier to switch between standard, membrane, and specialty platen configurations
• Anti-pinch safety guard – Helps protect the operator during automatic machine movement
• Front or rear garment loading – Allows garments to be threaded onto the platens from either direction
• Large workstation clearance – Provides additional working room between, beneath, and behind the platens
• Independent workstation timers – Configure pressing times separately for each platen
• Independent preheating settings – Set pre-press timing individually for each workstation
• 10 programmable recipes – Save frequently used time, temperature, and substrate settings
• Adaptive regulation – Helps optimize temperature control for sublimation, textile, DTG, and other applications
• Eco Mode – Helps reduce energy consumption during periods of inactivity
• Standby Mode – Adds additional energy-saving functionality when the press is not actively being used
• Dual production counters – Helps monitor production quantities
• Two 40 x 50 cm Nomex® covers included
• Two 45 x 55 cm Nomex® covers included
• Designed and manufactured in France
• 2-year machine warranty
• 10-year heating element warranty

Membrane Platen Applications

• Workwear and Uniforms
• Winter Jackets and Outerwear
• Garments with Zippers or Buttons
• Garments with Thick Seams
• Topstitched and Raised Pockets
• Lined Garments
• Products with Uneven or Raised Surfaces

Applications

• Heat Transfer Vinyl / Flex
• Screen Print Transfers
• Textile Sublimation
• Rigid Substrate Sublimation
• ChromaLuxe® Panels
• Laser Transfers
• Direct-to-Garment Applications
• DTG Pretreatment Drying
• Workwear and Thick Garment Decoration

Operating Modes

• Single-Platen Mode – Operates one workstation when dual-station production is not required
• Semi-Automatic Mode – Gives the operator greater control over shuttle movement and cycle progression
• Fully Automatic Mode – Automates pressing and head movement for maximum dual-station productivity

Digital Controls

• Multifunction touchscreen interface
• Independent press time for each workstation
• Precise temperature control
• Independent preheating time for each platen
• 10 programmable time / temperature / substrate recipes
• 3 selectable operating modes
• Adaptive regulation for different transfer applications
• Eco Mode
• Standby Mode
• Dual production counters

Specifications
