Sefa Sublimaxi 2513 255cm x 130cm Heat Press

The SEFA Sublimaxi 2513 255cm x 130cm Heat Press is SEFA's largest industrial heat press, engineered for extremely large-format sublimation production on textiles and rigid substrates. Developed in partnership with ChromaLuxe®, the Sublimaxi 2513 features a massive 255 x 130 cm (100" x 51") heating platen with a 250 x 125 cm (98" x 49") usable pressing area, providing the capacity needed for oversized panels, signage, displays, and high-value commercial sublimation work.

The Sublimaxi 2513 uses a dual-station motorized drawer system that allows operators to prepare one substrate while the opposite workstation is being pressed. Automatic drawer opening, closing, and switching create an efficient continuous-production workflow, helping minimize downtime between cycles while keeping large-format production moving.

To maintain consistent heat across its exceptionally large surface, the Sublimaxi 2513 features four independent concentric heating zones. These heating zones work together to promote uniform temperature distribution across the platen, helping produce consistent color and image quality throughout oversized sublimation transfers.

Uniform pressure is supported by six pneumatic cylinders positioned to distribute pressing force across the entire work area. With pressure up to 318 g/cm² and support for substrates up to 45 mm thick, the Sublimaxi 2513 is capable of handling large aluminum panels, ChromaLuxe® substrates, textiles, MDF, wood, and other rigid sublimation products.

A powerful 37,000 W heating system provides the thermal capacity required for industrial-scale sublimation, while the included dual air extraction system helps manage heat and vapors during production. SEFA's large touchscreen control panel provides precise PID temperature regulation, four recordable programs, a dual timer, resettable production counter, and energy-saving functionality.

Designed and manufactured in France, the SEFA Sublimaxi 2513 is built for professional sublimation facilities that require exceptionally large transfer capacity, automated dual-station production, and consistent heat and pressure across very large substrates.

Key Features

• SEFA's largest heat press – Built for extremely large-format professional sublimation production
• 100" x 51" heating platen – Provides a 250 x 125 cm (98" x 49") usable pressing area
• Dual motorized lower platens – Prepare one substrate while the opposite workstation is being pressed
• Automatic drawer movement – Automated opening, closing, and workstation switching help streamline high-volume production
• Four independent heating zones – Concentric heating zones help maintain consistent temperature across the oversized platen
• Six pneumatic cylinders – Help distribute pressure evenly across the entire pressing surface
• Up to 45 mm material thickness – Accommodates thick rigid substrates and specialty products
• Up to 318 g/cm² pressure – Provides consistent pneumatic pressure across extremely large transfers
• 37,000 W heating system – Delivers the heating capacity required for industrial large-format sublimation
• Dual air extraction system included – Helps manage heat and vapors during demanding production workflows
• Large touchscreen control panel – Provides convenient access to time, temperature, and production settings
• PID temperature regulation – Delivers precise and responsive heat control
• 4 programmable settings – Save commonly used production configurations for faster job changes
• Dual timer – Supports multi-step pressing workflows
• Resettable production counter – Helps monitor production quantities
• Energy-saving mode – Helps reduce unnecessary energy consumption during periods of inactivity
• Nomex®-covered heating platen included
• Developed in partnership with ChromaLuxe®
• Designed and manufactured in France
• 2-year machine warranty
• 10-year heating element warranty

Applications

• ChromaLuxe® Panels
• Extra-Large Rigid Substrate Sublimation
• Large-Format Textile Sublimation
• Heat Transfer Vinyl / Flex
• Oversized Aluminum Panels
• Large MDF and Wood Panels
• Commercial Signage and Displays
• Large Decorative and Photo Panels
• Specialty Industrial Sublimation Applications

Digital Controls

• SEFA-developed touchscreen interface
• PID temperature regulation
• 4 recordable programs
• Dual timer
• Resettable production counter
• Energy-saving mode

Specifications
