Sefa Duplex Mini Pro Cap & Logo Heat Press

The SEFA Duplex Mini Pro Heat Press is a professional dual-station pneumatic press designed for high-volume cap, logo, and small-format heat transfer production. Featuring an automatic shuttle system, pneumatic opening and closing, and two working stations, the Duplex Mini Pro is built to maximize output while reducing repetitive operator effort.

While one item is being pressed, the operator can load and prepare the second platen, helping minimize downtime between cycles. Once activated using the two-hand controls or foot pedal, the press automatically moves into position and completes the pressing cycle, creating a smooth and efficient workflow for repetitive production.

The Duplex Mini Pro can be configured with either 18 x 8 cm (7" x 3") cap platens or 16 x 16 cm (6" x 6") logo platens, making it ideal for high-volume production of decorated caps, chest logos, patches, labels, sleeves, and other small-format products. When configured for cap production, integrated cap tensioners help keep headwear securely positioned during pressing.

With pneumatic pressure up to 993 g/cm², the Duplex Mini Pro delivers strong, repeatable pressure from cycle to cycle. SEFA's advanced touchscreen electronics provide precise PID temperature regulation, adaptive control, up to four timers, ten programmable recipes, production counting, and energy-saving functions for reliable professional operation.

For decorators who need greater automation and throughput than a traditional single-station logo or cap press, the SEFA Duplex Mini Pro combines dual-station productivity, automatic platen movement, and pneumatic consistency in a compact production-focused system.

Key Features

• Automatic dual-station shuttle – Automatically moves between two workstations to help streamline high-volume production
• Pneumatic automatic opening and closing – Provides consistent pressure while reducing repetitive manual operation
• Dual-station workflow – Load and prepare one platen while the other item is being pressed
• Cap or logo configurations – Compatible with 18 x 8 cm cap platens or 16 x 16 cm logo platens
• Up to 993 g/cm² pressure – Delivers strong, repeatable pneumatic pressure for demanding transfer applications
• Two-hand or foot-pedal activation – Provides flexible cycle control depending on the production workflow
• Cap tensioners – Helps securely position caps during pressing when configured with cap platens
• Touchscreen controls – Intuitive interface for managing time, temperature, recipes, and production settings
• PID temperature regulation – Provides fast and precise heat control for consistent results
• Adaptive control parameters – Helps optimize performance for different decorating applications
• 10 programmable recipes – Save frequently used production settings for faster job changes
• Up to 4 timers – Supports more advanced and multi-step pressing workflows
• Cycle counter – Helps track production quantities
• Eco Mode – Helps reduce energy consumption during periods of inactivity
• Standby Mode – Provides additional energy-saving functionality when the press is not actively being used
• Stop-cycle function – Allows the operator to interrupt a pressing cycle when necessary
• Designed and manufactured in France
• 2-year machine warranty
• 10-year heating element warranty

Applications

• Heat Transfer Vinyl / Flex
• Screen Print Transfers
• Textile Sublimation
• Laser Transfers
• Direct-to-Garment Applications
• Caps and Headwear
• Logos and Chest Prints
• Patches, Labels, and Specialty Transfers

Digital Controls

• Touchscreen interface
• PID temperature regulation
• Adaptive control parameters
• 10 programmable recipes
• Up to 4 independent timers
• Cycle counter
• Eco Mode
• Standby Mode
• Stop-cycle function
• Platinum PT100 temperature sensor

Specifications

Cap and logo platens are sold separately. Select the appropriate platen configuration for your intended application.
