Sefa E-ROTEX PRO IND 40cm x 50cm Swing Away Heat Press

Data Sheet

The SEFA E-Rotex Pro IND 40cm x 50cm Swing Away Heat Press is a professional auto-open, auto-swing heat press built for efficient medium-volume production across a wide range of heat transfer applications. Featuring a full-size 40 x 50 cm (16" x 20") platen, powerful heating system, and automatic swing-away operation, it provides excellent access to the work area while helping streamline repetitive production.

At the end of each timed cycle, the press automatically opens and swings the heated upper platen away from the lower platen. This creates an unobstructed loading area for positioning garments and transfers while helping reduce the risk of over-pressing. The swing-away design also allows the heating platen to lift vertically from the substrate, making it especially well suited for thicker garments and rigid materials.

The IND version adds an integrated height indicator, giving operators a visual reference for platen height and pressure setup. This makes it easier to return to consistent settings when switching between garments, substrates, and production jobs—particularly useful in shops handling a variety of transfer applications throughout the day.

With a 2200 W heating system and pressure up to 590 g/cm², the E-Rotex Pro IND is capable of handling heat transfer vinyl, screen print transfers, textile sublimation, rigid substrate sublimation, ChromaLuxe® panels, laser transfers, and DTG-related processes such as pretreatment drying. Quick-change platens and front or rear garment loading add even more versatility for production environments.

Designed and manufactured in France, the E-Rotex Pro IND also features advanced SEFA digital controls with programmable preheating, five customizable recipes, adaptive temperature regulation, Eco Mode, and dual production counters. For decorators who need a versatile swing-away press with added setup repeatability, the E-Rotex Pro IND delivers a strong combination of automation, control, and professional production capability.

Key Features

• Integrated height indicator – Provides a visual reference for platen height and helps operators return to consistent pressure settings
• Automatic opening and swing-away operation – Automatically lifts and rotates the heated upper platen away at the end of each cycle
• 16" x 20" platen – Full-size pressing area for apparel, transfers, and rigid substrates
• Swing-away design – Provides unobstructed access to the lower platen for easier loading and positioning
• High-power heating system – 2200 W heating performance supports demanding transfer and DTG pretreatment applications
• Up to 590 g/cm² pressure – Provides strong, adjustable pressure for a wide variety of applications
• Quick-change platens – Makes it easier to configure the press for different garments and specialty products
• Front or rear garment loading – Allows T-shirts and other garments to be threaded onto the platen from either direction
• Digital time and temperature control – Precise settings for consistent, repeatable production
• 5 programmable recipes – Save frequently used time, temperature, and substrate settings
• Adaptive regulation – Helps optimize temperature control for sublimation, textile, DTG, and other applications
• Programmable preheating – Supports applications requiring a separate pre-press cycle
• Dual production counters – Helps track pressing quantities
• Eco Mode – Helps reduce energy consumption during periods of inactivity
• 40 x 50 cm Nomex® cover included
• Designed and manufactured in France
• 2-year machine warranty
• 10-year heating element warranty

Applications

• Heat Transfer Vinyl / Flex
• Screen Print Transfers
• Textile Sublimation
• Rigid Substrate Sublimation
• ChromaLuxe® Panels
• Laser Transfers
• Direct-to-Garment Applications
• DTG Pretreatment Drying

Digital Controls

• Time control
• Temperature control
• Programmable preheating time
• 5 programmable time / temperature / substrate recipes
• Adaptive regulation for different transfer applications
• Eco Mode
• Dual production counters
