Sefa Slide 655 64cm x 54cm Heat Press

The SEFA Slide 655 64cm x 54cm Heat Press is a large-format pneumatic heat press designed for professional sublimation and transfer production on oversized textiles and rigid substrates. Developed in partnership with ChromaLuxe®, the Slide 655 features a generous 64 x 54 cm (25" x 21") platen with a 60 x 50 cm (24" x 20") usable pressing area, making it especially well suited for work produced with 24" printers.

The pneumatic pressing system provides consistent pressure from cycle to cycle while reducing the physical effort required during large-format production. A front-loading slide-out lower platen extends almost completely clear of the heating area, giving operators excellent access for positioning larger garments, transfer sheets, panels, and rigid substrates before pressing.

With a maximum material thickness of 45 mm, pressure up to 363 g/cm², and a powerful 3300 W heating system, the Slide 655 is capable of handling demanding applications including ChromaLuxe® panels, rigid substrate sublimation, large-format textile sublimation, and heat transfer vinyl. Despite its larger format and heating capacity, the press operates from a conventional 240 V single-phase power supply.

SEFA's programmable touchscreen controls provide precise PID temperature regulation, ten recordable programs, dual timers, a resettable production counter, and energy-saving functionality. Designed and manufactured in France, the Slide 655 is an excellent choice for professional decorators and sublimation businesses that need a larger working area without moving to an industrial-sized production press.

Key Features

• Large-format pressing area – 64 x 54 cm platen with a 60 x 50 cm (24" x 20") usable transfer area
• Designed for 24" print workflows – Well suited for transfers produced using common 24-inch sublimation printers
• Pneumatic pressing – Provides consistent pressure while reducing repetitive operator effort
• Front slide-out lower platen – Extends almost completely clear of the heating area for easier loading and alignment
• Up to 45 mm material thickness – Accommodates thicker rigid substrates and specialty products
• Up to 363 g/cm² pressure – Provides strong, consistent pneumatic pressure across large transfers
• 3300 W heating system – Delivers the heating capacity required for large-format sublimation and rigid substrates
• SEFA touchscreen controls – Convenient interface for managing time, temperature, and saved production settings
• PID temperature regulation – Provides precise and responsive heat control for consistent results
• 10 programmable recipes – Save frequently used production configurations for faster job changes
• Dual timer – Supports multi-step applications and optional preheating workflows
• Resettable production counter – Helps track pressing quantities during production
• Energy-saving mode – Helps reduce unnecessary energy use during periods of inactivity
• 240 V single-phase operation – Provides large-format capability without requiring a three-phase electrical connection
• Developed in partnership with ChromaLuxe®
• Manufactured in France
• 2-year machine warranty
• 10-year heating element warranty

Applications

• ChromaLuxe® Panels
• Rigid Substrate Sublimation
• Large-Format Textile Sublimation
• Heat Transfer Vinyl / Flex
• Oversized Apparel and Textile Transfers
• Large Sublimation Panels and Specialty Products

Digital Controls

• SEFA-developed touchscreen interface
• PID temperature regulation
• 10 programmable programs
• Dual timer
• Resettable production counter
• Energy-saving mode
• Optional programmable preheating time
