Sefa Subli 1510+ 157cm x 107cm Heat Press

The SEFA Subli 1510+ 157cm x 107cm Heat Press is an industrial large-format pneumatic heat press designed for high-volume sublimation production on oversized textiles and rigid substrates. Developed in partnership with ChromaLuxe®, the Subli 1510+ features two motorized lower platens and a massive 157 x 107 cm (62" x 42") heating platen with a 152 x 102 cm (60" x 40") usable pressing area.

Its dual-station motorized drawer system allows operators to load and prepare one platen while the opposite station is being pressed. Automatic drawer opening, closing, and switching help create a continuous production workflow, reducing idle time between cycles and making the Subli 1510+ well suited for demanding commercial sublimation environments.

To maintain consistent heat across such a large surface, the Subli 1510+ uses two independent concentric heating zones designed to promote even temperature distribution across the platen. Four pneumatic cylinders help distribute pressure uniformly throughout the pressing area, supporting consistent transfers on large aluminum panels, textiles, MDF, wood, tiles, and other sublimation-ready substrates.

With support for materials up to 45 mm thick, pressure up to 296 g/cm², and a powerful 17,500 W heating system, the Subli 1510+ is engineered for industrial-scale production. Its large-format capacity makes it ideal for high-definition sublimation graphics, oversized textile prints, rigid display panels, signage, photo panels, and other applications requiring consistent heat and pressure over a very large transfer area.

SEFA's large touchscreen control system provides precise PID temperature regulation, four recordable programs, a dual timer, resettable production counter, and energy-saving functionality. Designed and manufactured in France, the Subli 1510+ delivers the automation, platen capacity, and production efficiency required by professional sublimation shops handling large-format work at scale.

Key Features

• Industrial large-format capacity – 157 x 107 cm platen with a 152 x 102 cm (60" x 40") usable pressing area
• Dual motorized lower platens – Prepare one substrate while the opposite workstation is being pressed
• Automatic drawer movement – Automated opening, closing, and workstation switching help streamline production
• Dual-station workflow – Allows loading and preparation to continue on the free platen during each pressing cycle
• Two independent heating zones – Concentric heating zones promote consistent temperature distribution across the oversized platen
• Four pneumatic cylinders – Help distribute pressure evenly across the entire pressing surface
• Up to 45 mm material thickness – Accommodates thicker rigid substrates and specialty products
• Up to 296 g/cm² pressure – Provides consistent pneumatic pressure across large-format transfers
• 17,500 W heating system – Delivers the heating capacity required for industrial large-format sublimation
• Large touchscreen control panel – Provides convenient access to time, temperature, and production settings
• PID temperature regulation – Provides precise and responsive heat control
• 4 programmable settings – Save commonly used production configurations for faster job changes
• Dual timer – Supports multi-step production workflows
• Resettable production counter – Helps monitor pressing quantities
• Energy-saving mode – Helps reduce unnecessary energy consumption during periods of inactivity
• Designed in partnership with ChromaLuxe®
• Nomex®-covered platen included on ChromaLuxe configuration
• Designed and manufactured in France
• 2-year machine warranty
• 10-year heating element warranty

Applications

• ChromaLuxe® Panels
• Large-Format Rigid Substrate Sublimation
• Large-Format Textile Sublimation
• Heat Transfer Vinyl / Flex
• Aluminum Sublimation Panels
• MDF and Wood Panels
• Tiles and Other Rigid Sublimation Substrates
• Oversized Signage and Display Graphics
• Large Photo and Decorative Panels

Digital Controls

• SEFA-developed touchscreen interface
• PID temperature regulation
• 4 recordable programs
• Dual timer
• Resettable production counter
• Energy-saving mode

Specifications
