This new pneumatic press is equipped with a front drawer which allows it to be integrated into a small space. It is also equipped with a reversible sleeve and the Quick Release tray attachment system.
It comes in two versions: e-SLIDE 540 LITE and e-SLIDE 540 PRO
Air-operated manual (LITE) and auto-swing (PRO) press.
Nomex® cover of 40x50cm included.
Strengths :
- High heating power for drying the pre-treatment in DTG Pneumatic opening and closing (Lite & PRO)
- Pneumatic opening and closing (Lite & PRO)
- Front release of the tray by manual drawer (Lite) or pneumatic (PRO)
- Designed and manufactured in France
- Two-year machine warranty
- Ten-year warranty on heating elements
Electronics :
- Time
- Temperature
- Preheating time
- 10 recipes time/temperature/substrate
- Adaptive regulation depending on the application (sublimation, textile, DTG)
- Eco mode
- Standby mode
- Double pieces counter
SLIDE 540 LITE:
Manual drawer
Pneumatic press
Bi-manual command
Power 2200W
SLIDE 540 PRO
Pneumatique assist drawer
Pneumatic press
Automatic drawer for opening and closing
Bi-manual command
Power 2200W
| Type | Pneumatic, Manual |
| Operation | Pneumatic opening and closing (Lite & PRO) and Front release of the tray by manual drawer (Lite) or pneumatic (PRO) |
| Platen size | 40x50 cm / 16x20 " |
| Weight | 81 Kg / 179 lbs |
| Pressure | 363 g/cm² |
| °C / °F Max | 220 °C / 429 °F |
| Power | 2200W |
| Power supply | 240 V Single-phase + Neutral + Ground |
| Amperage | 10A |
| Applications | ChromaLuxe, Flex, Direct to Garment, Pretreatment, Sublimation Rigid Substrate, Textile Sublimation, Screen Printing, Laser Transfer |
| Dimension | 621x847x572 mm / 24x33x22 " |
