The STAHLS' Hotronix® Dual Air Fusion IQ® is built for high-volume apparel decorators who need to keep the press working while the next garment is being loaded. Two 40 x 50 cm lower platens flank a pneumatically controlled moving heat head, allowing one station to be prepared while the other is pressing.
Independent station control, foot-pedal operation, automatic pressure control, and the IQ® touchscreen help reduce repetitive operator steps and improve consistency across long production runs. Both lower stations support the Hotronix® Quick-Change platen system for specialty garments and print locations. An air compressor is required and is not included.
Key Features
- Dual-station pneumatic production heat press
- Two 40 x 50 cm lower platens
- Moving heat head for continuous load-and-press workflow
- IQ® touchscreen with time, temperature, pressure, and production controls
- Automatic pressure adjustment and foot-pedal operation
- Quick-Change interchangeable lower platens
- Maximum temperature: 220°C / 430°F
European Specifications
| Electrical | Net Weight | Shipping Weight | Approx. Machine Dimensions |
|---|---|---|---|
| 240V / 15A / 3500W | 120 kg | 200 kg | 97 x 97 x 66 cm |
Warranty
30-year warranty on the heating element; 5-year warranty on the frame; 2-year warranty on the press excluding wear parts.
